Key note highlight

The RRC2020 is a standard battery pack

The RRC2020 is a standard battery pack from the POWERPAQ series, manufactured by RRC Power Solutions. Utilizing advanced lithium-ion technology, it is a high-energy-density, ready-to-use "smart" battery solution. It complies with the SMBus standard and features an integrated LED state-of-charge (SoC) indicator. This battery pack is widely applicable in medical devices, instrumentation, robotics, drone/UAV power systems, and IoT/wearable equipment.

Key Specifications

The table below summarizes the core technical parameters, based on the official product datasheet and distributor information.

Parameter	Specification
Model	RRC2020
Chemistry	Lithium-Ion (Li-Ion)
Nominal Voltage	10.80 V or 11.25 V
Nominal Capacity	9.22 Ah or 8.85 Ah
Rated Energy	99.60 Wh
Cell Configuration	3S3P
Max. Charge Voltage	12.55 V or 13.05 V
Max. Charge Current	6.20 A
Max. Discharge Current	10.00 A
Dimensions (L x W x H)	149.7 mm x 89.25 mm x 20.1 mm (Max)
Weight	Approx. 490 g - 505 g
Cycle Life	80% of initial capacity after 800 cycles
Operating Temperature	Charge: 0°C to 45°C; Discharge: -20°C to 60°C
Storage Temperature	Recommended: -20°C to 25°C; Max: -20°C to 50C
Communication Bus	SMBus
Ingress Protection	IP40

Interface & Safety Features

Contact Definition: Battery contacts include +(Positive), C(Clock), D(Data), T(Temperature), and -(Negative).
Comprehensive Protection: The battery integrates multiple safety protections:
- CUV/COV: Cell Under-Voltage / Over-Voltage Protection
- OTC/OTD: Over-Temperature during Charge / Discharge Protection
- OCC/OCD: Over-Current during Charge / Discharge Protection
- SCC/SCD: Short-Circuit during Charge / Discharge Protection
- CTO: Charge Time-Out Protection

Compliance & Certifications

The RRC2020 battery pack has obtained major global safety and quality certifications, ensuring compliance with international standards, including: IEC62133, UL2054, CE, FCC, UKCA, KC, PSE, UN38.3, RoHS, REACH, etc.
